Products Show

RG-2D vertical slitter

Stable quality: the implementation of the whole process quality monitoring, meticulous, and all aspects of testing!
Reasonable price: effective internal cost control, reducing expenses and benefiting customers!
Fast delivery: advanced production line, sufficient stocking, shorten the delivery time!

Tel：

Product Details

RG-D high-speed vertical slitter

1. The machine is a vertical slitter.

2. Independent control panel, the operation more flexible and convenient.

3. Unwinding automatic correction, photoelectric eye for tracking the edge of transparent materials and color.

4. Unwinding tension is controlled by magnetic powder brake.

5. Rolling is controlled by magnetic clutch.

6. With the side of the material to send or take the device (when ordering).

7. Take the length of the automatic meter meter.

8. Roll the roll to make the web more flat.

9. Double inflatable reel

10 automatic volume tension.

RG-A vertical slitter parameters:

The appearance, technical parameters, performance and features of the machine are subject to change without notice. Without the express written permission of Ruiguang company, may be reproduced or the dissemination of relevant information
